i have used virtual box you can also use vmware or other hypervisor
Creating network interfaces ( 3 interfaces )
File > Preferences > Network > Host-only Networks
Interface 1 (Management Network)
IPv4 Address: 10.10.10.1
Network Mask: 255.255.255.255.0
Interface 2 (Tunnel Network)
IPv4 Address: 10.20.20.1
Network Mask: 255.255.255.255.0
Interface 3 (External Network)
IPv4 Address: 192.168.100.1
Network Mask: 255.255.255.255.0
Create a vm - controller
Install Ubuntu Server 14.10
Assign network adapter
Settings > Network
Adapter 1:
Attached to: Host-only Adapter
Name: Interface 1
Adapter Type: Paravirtualized Network
Promiscuous Mode: Allow All
Adapter 2:
Attached to: NAT
Adapter Type: Paravirtualized Network
Always use root user
$ sudo su
In Controller Node
Configuring Hostname
# nano /etc/hostname
controller
Configuring Network Interfaces
# nano /etc/network/interfaces
auto eth0
iface eth0 inet static
address 10.10.10.10
netmask 255.255.255.0
auto eth1
iface eth1 inet dhcp
Configuring Name resolution
# nano /etc/hosts
10.10.10.10 controller
10.10.10.11 compute
10.10.10.12 network
10.10.10.13 block
10.10.10.14 object1
10.10.10.15 object2
#127.0.0.1 localhost
# reboot
Update Ubuntu Server
# sudo apt-get update
Clone Controller Node (Full Clone)
-network
-compute
Assign network adapter
To Network Node
Adapter 1:
Attached to: Host-only Adapter
Name: Interface 1
Adapter Type: Paravirtualized Network
Promiscuous Mode: Allow All
Adapter 2:
Attached to: Host-only Adapter
Name: Interface 2
Adapter Type: Paravirtualized Network
Promiscuous Mode: Allow All
Adapter 3:
Attached to: Host-only Adapter
Name: Interface 3
Adapter Type: Paravirtualized Network
Promiscuous Mode: Allow All
Adapter 4:
Attached to: NAT
Adapter Type: Paravirtualized Network
To Compute Node
Adapter 1:
Attached to: Host-only Adapter
Name: Interface 1
Adapter Type: Paravirtualized Network
Promiscuous Mode: Allow All
Adapter 2:
Attached to: Host-only Adapter
Name: Interface 2
Adapter Type: Paravirtualized Network
Promiscuous Mode: Allow All
Adapter 3:
Attached to: NAT
Adapter Type: Paravirtualized Network
In Network Node
Configuring Hostname
# nano /etc/hostname
network
Configuring Network Interfaces
# nano /etc/network/interfaces
auto eth0
iface eth0 inet static
address 10.10.10.12
netmask 255.255.255.0
auto eth1
iface eth1 inet static
address 10.20.20.12
netmask 255.255.255.0
auto eth2
iface eth2 inet manual
up ip link set dev $IFACE up
down ip link set dev $IFACE down
auto eth3
iface eth3 inet dhcp
# reboot
# ping controller
# ping compute
# ping google.com
In Compute Node
Configuring Hostname
# nano /etc/hostname
compute
Configuring Network Interfaces
# nano /etc/network/interfaces
auto eth0
iface eth0 inet static
address 10.10.10.11
netmask 255.255.255.0
auto eth1
iface eth1 inet static
address 10.20.20.11
netmask 255.255.255.0
auto eth2
iface eth2 inet dhcp
# reboot
# ping controller
# ping network
# ping google.com
In Controller Node
# ping network
# ping compute
# ping google.com
Clone Network Node (Full Clone) - backup (for later use)
