OpenStack Juno: Installation using VirtualBox & Ubuntu 14.10 ( Object Storage - Swift ) - 12

Clone Object1 Node (Full Clone) - object2

In Object1 Node

Configuring Hostname

# nano /etc/hostname

object2

Configuring Network Interfaces

# nano /etc/network/interfaces

auto eth0
iface eth0 inet static
address 10.10.10.15
netmask 255.255.255.0

auto eth1
iface eth1 inet dhcp

# reboot

Change ip in config files

# nano /etc/rsyncd.conf

address = 10.10.10.15

# nano /etc/swift/account-server.conf

bind_ip = 10.10.10.15

# nano /etc/swift/container-server.conf

bind_ip = 10.10.10.15

# nano /etc/swift/object-server.conf

bind_ip = 10.10.10.15

Create Initial Rings (In Controller Node)

# cd /etc/swift

Account ring

# swift-ring-builder account.builder create 10 3 1

# swift-ring-builder account.builder add r1z1-10.10.10.14:6002/sdb 100

# swift-ring-builder account.builder add r1z1-10.10.10.14:6002/sdc 100

# swift-ring-builder account.builder add r1z1-10.10.10.15:6002/sdb 100

# swift-ring-builder account.builder add r1z1-10.10.10.15:6002/sdc 100

# swift-ring-builder account.builder

# swift-ring-builder account.builder rebalance

Container ring

# swift-ring-builder container.builder create 10 3 1

# swift-ring-builder container.builder add r1z1-10.10.10.14:6001/sdb 100

# swift-ring-builder container.builder add r1z1-10.10.10.14:6001/sdc 100

# swift-ring-builder container.builder add r1z1-10.10.10.15:6001/sdb 100

# swift-ring-builder container.builder add r1z1-10.10.10.15:6001/sdc 100

# swift-ring-builder container.builder

# swift-ring-builder container.builder rebalance

Object ring

# swift-ring-builder object.builder create 10 3 1

# swift-ring-builder object.builder add r1z1-10.10.10.14:6000/sdb 100

# swift-ring-builder object.builder add r1z1-10.10.10.14:6000/sdc 100

# swift-ring-builder object.builder add r1z1-10.10.10.15:6000/sdb 100

# swift-ring-builder object.builder add r1z1-10.10.10.15:6000/sdc 100

# swift-ring-builder object.builder

# swift-ring-builder object.builder rebalance

Distribute ring config files

# ll

# apt-get install openssh-server

* Install openssh-server on Controller, Object1, Object2 Nodes

# rm -rf .ssh/

# ssh chaal@object1

# ssh chaal@object1

# chown chaal /etc/swift

* change ownership /etc/swift on Controller, Object1, Object2 Nodes

# cd /etc/swift

# scp account.ring.gz container.ring.gz object.ring.gz chaal@object1:/etc/swift

# scp account.ring.gz container.ring.gz object.ring.gz chaal@object2:/etc/swift

# curl -o /etc/swift/swift.conf https://raw.githubusercontent.com/openstack/swift/stable/juno/etc/swift.conf-sample

# nano /etc/swift/swift.conf

[swift-hash]
...
swift_hash_path_suffix = chaal
swift_hash_path_prefix = pritam

[storage-policy:0]
...
name = Policy-0
default = yes

# scp swift.conf chaal@object1:/etc/swift

# scp swift.conf chaal@object2:/etc/swift

# cd

# chown -R swift:swift /etc/swift

* change ownership /etc/swift on Controller, Object1, Object2 Nodes

# service memcached restart

# service swift-proxy restart

# swift-init all start

* Start object storage services on Object1, Object2 Nodes

Verifying Object Storage Services

# source demo-openrc.sh

# swift stat

# touch testfile

# swift upload democontainer testfile

# swift list

# swift download democontainer testfile
